UMTS2100mhz / DCS 1800mhz Dual Band Booster Cellular Networks 2g 3g 4g

Brand Name : ATNJ

Model Number : JS-DB1800/2100

Certification : CE,ROHS，CCC，TUV,BV， ISO

Place of Origin : China

MOQ : 5Pcs

Price : USD+95---120+kit

Payment Terms : T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability : 1000+unit+per day.

Delivery Time : 3 work days

Packaging Details : Standard neutral packing,52x21x16cm(1 kit), 4kits as 1 carton(53x49x42cm)

DCS Frequency Range : 1710-1785MHz / 1805-1880MHz

UMTS Frequency Range : 1920-1980MHz / 2110-2170MHz

Products Type : Signal repeater 4G

Color : Gold & Black & White & Customized

Weight : 4kg

Warranty : 3 Years

Contact Now

1.Sample Orders are supported.
2.Fast delivery.We can send the sample in 1days after getting your payment
3.OEM ODM service is available. We can make customized logo,frequency on product and packing
according to your requirement.
4.2 year warranty
5.CE approval
UMTS2100mhz / DCS 1800mhz Dual Band Booster Cellular Networks 2g 3g 4g
Product Description
UMTS2100mhz / DCS 1800mhz Dual Band Booster Cellular Networks 2g 3g 4g
UMTS2100mhz / DCS 1800mhz Dual Band Booster Cellular Networks 2g 3g 4g
UMTS2100mhz / DCS 1800mhz Dual Band Booster Cellular Networks 2g 3g 4g
UMTS2100mhz / DCS 1800mhz Dual Band Booster Cellular Networks 2g 3g 4g

Technical Specifications

Specifications

Parameters

Frequency Range (Customers to Choose)

Uplink

1710-1785MHz, 1920-1980MHz

Downlink

1805-1880MHz, 2110-2170MHz

Frequency Bandwidth

75MHz&60MHz

Gain

70dB

Automatic gain control (Step Attenuation)

31dB @ 1dB/ Step

Auto Gain Control

20dB Min.

Output Power(Customers to Choose)

20dBm

Spurious Emission

≤ -15dBm/30kHz

9kHz~1GHz: ≤ -36dBm/30kHz

1GHz~12.75GHz: ≤ -30dBm/30kHz

Inter-Modulation Attenuation ACPR

≤ -40dBc / 30kHz (measured under rated output power)

In-band Ripple

≤ 3dB

VSWR

<=2

I/O Impedance

50 Ω

Noise Figure

≤ 5dB

System Delay

≤ 5μs

RF Connector(Customers to Choose)

N(Female)

Operating Temperature

Operation: - 10°C ~ + 55°C / Storage: -20°C ~ +60°C

Power Supply

AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)

Dimensions

165*130*40 (mm)

Weight

≤0.8 kg(Net)

Alarm Monitoring System

Alarm for uplink self-oscillation

Indication LED

Power supply

Further detail pls click here for downloading the products specification:

1800+2100MHz A032 mobile signal repeater.pdf

FAQ:

1.

Q: Why choose us for cooperation?

A: We have the professional engineer to develop and make them suit for all over the world.we also will deal with all the problem when you have problem and reply to you at any time.

2.

Q: Does the signal booster work have radiation or not ?

A: Yes,but just little ,it also can reduce the radiation when you calling ,because it will have more radiation if no signal when you dialing on your phone.So don’t worry and use in house ,it is better for you than not use when no signal in house.

3.

Q: Can I install a signal repeater myself?

A: Absolutely. There is no technical expertise required to install your mobile signal repeater kit. Each kit contains everything needed to improve the mobile coverage in your home/office and includes instructions that will guide you through the simple steps necessary to install your repeater.

4.

Q: Can this mobile signal repeater create a signal where there is no cell signal before?

A: The mobile signal repeater cannot produce a signal, only amplify a weak one.
